Appendix
Code table
12
318
EDBCSXM064 EN 11.0
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C2382 The XCAN monitoring is
configured if no telegrams have
been received.
(AIF interface X1)
1 XCAN Conf. CE 0 Off XCAN1_IN
2 XCAN Conf. CE 0 Off XCAN2_IN
3 XCAN Conf. CE 0 Off XCAN3_IN
4 XCAN Conf. CE 0 Off Bus−off
5 XCAN Conf. CE 0 Off Life Guarding / Heartbeat Event
6 XCAN Conf. CE 0 Off Response to sync reception
0 Off
1 Controller inhibit (CINH)
2 Quick stop (QSP)
C2450 CANa address 1
Node address for CAN bus
interface X14 (CAN−AUX)
197
351
1 {1} 63 This code is inactive if one of DIP
switches 2 ... 7 and switch 1 are
set to "ON".
C2451 CANa baud
rate
0
Baud rate for CAN bus interface
X14 (CAN−AUX)
197
0 500 kBit/s
1 250 kBit/s
2 125 kBit/s
3 50 kBit/s
4 1000 kBit/s
C2452 CANa mst 0
Configuration of master/slave
for CAN bus interface X14
(CAN−AUX)
203
0 Slave
1 Master
C2453 Source for system bus node
addresses of
CANaux_IN/CANaux_OUT (CAN
bus interface X14)
201
1 CANa addr sel 0 CAN node address (C2450) Address CANaux1_IN/OUT
2 CANa addr sel 0 CAN node address (C2450) Address CANaux2_IN/OUT
3 CANa addr sel 0 CAN node address (C2450) Address CANaux3_IN/OUT
0 C2450 (auto) Automatically determined by
C2450
1 C2454 (man.) Determined by C2454
C2454 Alternative node addresses for
CANaux_IN/CANaux_OUT (CAN
bus interface X14)
201
1 CANa addr. 129 1 {1} 512 CANaux1_INaddress 2
2 CANa addr. 1 CANaux1_OUTaddress 2
3 CANa addr. 257 CANaux2_INaddress 2
4 CANa addr. 258 CANaux2_OUTaddress 2
5 CANa addr. 385 CANaux3_IN address 2
6 CANa addr. 386 CANaux3_OUT address 2
