Appendix
Code table
12

319
EDBCSXM064 EN 11.0
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C2455 Identifier for
CANaux_IN/CANaux_OUT (CAN
bus interface X14)
Read only
 351
1 CANa Id 1 {1} 2047 Identifier CANaux1_IN
2 CANa Id Identifier CANaux1_OUT
3 CANa Id Identifier CANaux2_IN
4 CANa Id Identifier CANaux2_OUT
5 CANa Id Identifier CANaux3_IN
6 CANa Id Identifier CANaux3_OUT
C2456 CAN time settings for CAN bus
interface X14 (CAN−AUX)
 204
1 CANa times 3000 0 {1 ms} 65000 CAN−AUX boot−up time:
Delay time after mains
connection for initialisation
through the master.
2 CANa times 0
CANaux2...3_OUT cycle times:
Factor for the task time to send
process data telegram.
0 = event−controlled
transmission
3 CANa times 0
4 CANa times 20 Delay time for initial
transmission of the process data
objects 2 and 3 after the CAN bus
changed to "Operational"
C2457 Monitoring time for
CANaux1...3_IN (CAN bus
interface X14)
 225
1 CE monit time 3000 1 {1 ms} 65000 CE11 monitoring time
2 CE monit time 3000 CE12 monitoring time
3 CE monit time 3000 CE13 monitoring time
C2458 Reset node 0
Resetting a node
(CAN bus interface X14)
 206
0 No function
1 CAN−AUX reset
C2459 CANa state
CAN bus status (CAN bus
interface X14)
Read only
 214
0 Operational
1 Pre−operational
2 Warning
3 Bus off
