Code table
12

320
EDBCSXM064 EN 11.0
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C2460 Telegram counter
CANaux_IN/CANaux_OUT (CAN
bus interface X14), number of
telegrams
Read only
 215
1 CANa
Messages
0 {1} 65535 All sent telegrams
2 CANa
Messages
With a count value > 65535 the counter restarts
with 0
All received telegrams
3 CANa
Messages
Sent to CANaux1_OUT
4 CANa
Messages
Sent to CANaux2_OUT
5 CANa
Messages
Sent to CANaux3_OUT
6 CANa
Messages
Sent to parameter data
channel 1
7 CANa
Messages
Sent to parameter data
channel 2
8 CANa
Messages
Received from CANaux1_IN
9 CANa
Messages
Received from CANaux2_IN
10 CANa
Messages
Received from CANaux3_IN
11 CANa
Messages
Received from parameter data
channel 1
12 CANa
Messages
Received from parameter data
channel 2
C2461 Detected load
CANaux_IN/CANaux_OUT (CAN
bus interface X14)
Read only
A faultless operation is only
guaranteed if the total bus load
of all connected nodes amounts
to a value £ 80 %.
 216
1 Load IN/OUT 0 {1 %} 100 All sent telegrams
2 Load IN/OUT All received telegrams
3 Load IN/OUT Sent to CANaux1_OUT
4 Load IN/OUT Sent to CANaux2_OUT
5 Load IN/OUT Sent to CANaux3_OUT
6 Load IN/OUT Sent to parameter data
channel 1
7 Load IN/OUT Sent to parameter data
channel 2
8 Load IN/OUT Received from CANaux1_IN
9 Load IN/OUT Received from CANaux2_IN
10 Load IN/OUT Received from CANaux3_IN
11 Load IN/OUT Received from parameter data
channel 1
12 Load IN/OUT Received from parameter data
channel 2
