Code table
12

325
EDBCSXM064 EN 11.0
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C3022 DCC−CTRL
enable
1.0
Deceleration time:
Within this time, the manual jog
speed (C3020) is reduced to zero.
 165
0.000 {1 s} 999.000
C3030 FolloErrWarn 400000 Following error limit for enabling
a warning
 170
0 {1 inc} 2140000000
C3031 FolloErrFail 800000 Following error limit for enabling
a FAIL−QSP
(Quick stop (QSP) is executed.)
 170
0 {1 inc} 2140000000
C3032 FollErr1reac 2 First reaction when following
error limit has been reached
 170
0 TRIP
1 Message
2 Warning
3 Off
4 FAIL−QSP
C3033 FollErr2reac 4 Second reaction when following
error limit has been reached
 170
0 TRIP
1 Message
2 Warning
3 Off
4 FAIL−QSP
C3034 FollowErrDisp 0 Following error
Read only
 170
−2147483647 {1 units} 2147483647
C3037 VelModeErr 25.0
Speed deviation for enabling the
response to speed errors (C3038)
0.00 {0.01 %} 100.00
C3038 VelModeErr
Reac
3
Response to speed errors in
"Velocity Mode" (C5000 = 2)
0 TRIP
1 Message
2 Warning
3 Off
4 FAIL−QSP
C3150 Stateword 0 Status word
Read only
 134
0 {1 units} 65535
