Appendix
Code table
12

326
EDBCSXM064 EN 11.0
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C3151 Status word (in bits)
Read only
 134
0 {1 bit} 1
1 StateBit 0 Bit 0 Toggle bit
2 StateBit 0 Bit1 Operating mode−oriented function
3 StateBit 0 Bit2 Operating mode−oriented function
4 StateBit 0 Bit3 Operating mode−oriented function
5 StateBit 0 Bit4 Operating mode−oriented function
6 StateBit 0 Bit5 Positive hardware limit switch
7 StateBit 0 Bit6 Negative hardware limit switch
8 StateBit 0 Bit 7 Reserved
9 StateBit 0 Bit 8 Status information 0
10 StateBit 0 Bit 9 Status information 1
11 StateBit 0 Bit10 Status information 2
12 StateBit 0 Bit11 Status information 3
13 StateBit 0 Bit12 Warning
14 StateBit 0 Bit13 Actual position OK
15 StateBit 0 Bit14 FailToAckn
(Reset fault message)
16 StateBit 0 Bit15 Controller is ready for operation
C3152 Controlword 0 Control word
Read only
 131
0 {1 units} 65535
C3153 Control word (in bits)
Read only
 131
0 {1 bit} 1
1 ControlBit 0 Bit 0 Toggle bit
2 ControlBit 0 Bit 1 Not assigned
3 ControlBit 0 Bit 2 Brake relay
4 ControlBit 0 Bit 3 Quick stop (QSP)
5 ControlBit 0 Bit 4 Monitor data selection
6 ControlBit 0 Bit 5 Monitor data selection
7 ControlBit 0 Bit 6 Monitor data selection
8 ControlBit 0 Bit 7 Controller enable
9 ControlBit 0 Bit 8 Operation inhibit
10 ControlBit 0 Bit 9 Controller inhibit (CINH)
11 ControlBit 0 Bit 10 Set fault message (TRIP−SET)
12 ControlBit 0 Bit 11 Reset fault message
(TRIP RESET)
13 ControlBit 0 Bit 12 Operating mode−oriented function
14 ControlBit 0 Bit 13 Operating mode−oriented function
15 ControlBit 0 Bit 14 Not assigned
16 ControlBit 0 Bit 15 Reserved
