Code table
12

327
EDBCSXM064 EN 11.0
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C3160 ToggleErrReac 3 Toggle bit error handling
 136
0 TRIP
1 Message
2 Warning
3 Off
4 FAIL−QSP
C3161 ToggleErLimit 4 Toggle bit error counter limit
 136
0 {1 units} 65535
C3162 ToggleBitFail 0 Toggle bit error counter
Read only
0 {1 units} 65535
C3165 SyncInside
Win
0 CAN synchronisation inside the
window
Read only
 209
0 {1 bit} 1
C3170 NoHoming
Reac
3 Reaction, when the reference is
not known.
0 TRIP
1 Message
2 Warning
3 Off
4 FAIL−QSP
C3175 HW EndReac 4 Reaction, when a hardware limit
switch is activated.
 172
0 TRIP
1 Message
2 Warning
3 Off
4 FAIL−QSP
C3180 MonitorData 0 Monitor data selection
Read only
 133
0 {1 units} 7
C3181 MonitorData 0
Monitor data selection
 133
0 Free
1 MCTRL_nPos_a Actual position (16 bits) referred
to one revolution (rotor position)
2 DINT_TO_INT
(MCTRL_dnPosSet_p)
Following error ±2
15
3 MCTRL_nNAct_a Actual speed (n
max
= 2
14
)
4 MCTRL_nMAct_a Actual torque (M
max
= 2
14
)
5 MCTRL_nIAct_a Actual motor current (I
max
= 2
14
)
6 MCTRL_nDCVolt_a Actual DC−bus voltage
(2
14
¢ 1000 V)
7 PosLatchDiff Difference between actual
position and position at touch
probe (C6000)
C3200 Act.Fault 0 All fault indications
(TRIP, FAIL−QSP, warning, message)
Current fault
Read only
 270
