Electrical installation
Parallel connection
Braking units with brake resistor
6
87
EDBMB935X DE/EN/FR 11.0
Stop!
Correct synchronisation of braking units connected in parallel:
ƒ Set switching thresholds of all braking units to the same value
(see chapter 6.6).
ƒ Connect synchronisation interfaces correctly
– Output: A1, A2 / input E1, E2
– For total lengths £ 0.5 m you do not have to use shields.
ƒ Configuring braking units with switch S3 as master and slave:
– Configure the first braking unit in the interconnection as
master (S3 = OFF).
– Configure each further braking unit within the interconnection
as slave (S3 = ON).
