Operation
Calling up help messages
6

83
EDBPM−H502 DE/EN/FR 5.1
6.5 Calling up help messages
ƒ Help messages
– can be assigned to page or information messages,
– contain useful notes to make handling easier,
– must be programmed in the »HMI Designer« planning tool,
– for information messages can be up to 16 lines × 34 characters long
(normal character size),
– for project pages can be up to 16 lines × 40 characters long (normal
character size).
You want to ... Touch the fields ... Example
A
call up the help message for an
information message.
1. Touch the programmed field "HELP".
ESC
Pressure exceeds
safety limit
125.5
13-09-2000 10:45a HELP
Temperature exceeds
safety limit
1700
13-09-2000 10:55a HELP
2. Close help.
ESC
B
call up the help message for a page.
1. Touch the programmed field that is
assigned to the Open help page"
function.
2. Close help.
ESC
