Lenze I51AE175F - Mains Connection

Installaon of shield connecon sheet for motor cable 7.5 kW to 11 kW for I5xAE (oponal accessories)
2 Nm
(17.7 lb-in)
❶ ❷
M4x12
❸
Installaon of shield connecon sheet for motor cable 7.5 kW to 11 kW for I5xBE (oponal accessories)
2 Nm
(17.7 lb-in)
TX20
1
2
3
1.
2.
3.
Dimensions
The specied installaon clearances are minimum dimensions to ensure a sucient air circulaon
for cooling purposes. They do not consider the bend radiuses of the connecng cables.
Several i5xx frequency inverters can be mounted directly next to each other, regardless of the device
size. No installaon clearance is required between the devices.
Mechanical installaon
Preparaon
18
