3-phase mains connecon 230/240 V "Light Duty"
Rated data
The inverters I51AExxxC do not have an integrated RFI lter in the AC mains supply.
In order to meet the EMC requirements according to EN 61800−3, an external EMC lter according
to IEC EN 60939 must be used.
The user must verify that the conformity with EN 61800−3 is fullled.
The output currents apply to these operang condions:
•
At a switching frequency of 2 kHz or 4 kHz: Ambient temperature above 40 °C with a rated output current
reduced by 2.5 %/°C.
•
If the load characterisc "Light Duty" and the switching frequencies 8 kHz or 16 kHz are selected, only the
values of the load characterisc "Heavy Duty" are reached.
Inverter I51AE
240C 255C
Rated power P
rated
kW 5.5 7.5
Rated power P
rated
hp 7.5 10
Mains voltage range 3/PE AC 195 V ... 264 V, 45 Hz ... 65 Hz
Output voltage 3 AC 0 - 230/240 V
Rated mains current
without mains choke A 25.8 -
with mains choke A 18.9 24.2
Apparent output power kVA 8 10.5
Rated output current
2 kHz A 16.5 23
4 kHz A 16.5 19.3
8 kHz A -
16 kHz A -
Power loss
2 kHz W 124 190
4 kHz W 131 200
8 kHz W -
16 kHz W -
Cyclic mains switching 3 mes per minute
Brake chopper
Max. output current -
Min. brake resistance -
Max. motor cable length
shielded
without EMC category m 50
Category C1 (2 kHz, 4 kHz,
8 kHz)
m -
Category C2 (2 kHz, 4 kHz,
8 kHz)
m -
Category C3 (2 kHz, 4 kHz,
8 kHz)
m -
Max. motor cable length
unshielded
without EMC category m -
Technical data
3-phase mains connecon 230/240 V "Light Duty"
Rated data
