Inverter I51BE I51AE I51BE
275F 311F
Rated power P
rated
kW 7.5 11
Rated power P
rated
hp 10 15
Mains voltage range 3/PE AC 340 V ... 528 V, 45 Hz ... 65 Hz
Output voltage 3 AC 0 - 400/480 V
Rated mains current
without mains choke A 16.6 23.7
with mains choke A 13.1 18.6
Apparent output power kVA 11 16
Rated output current
2 kHz A 14 21
4 kHz A 14 21
8 kHz A 14 21
16 kHz A 9.3 14
Power loss
2 kHz W 172 242
4 kHz W 185 260
8 kHz W 240 340
16 kHz W 238 337
Cyclic mains switching 3 mes per minute
Brake chopper
Max. output current -
Min. brake resistance -
Max. motor cable length
shielded
without EMC category m 100
Category C1 (2 kHz, 4 kHz,
8 kHz)
m -
Category C2 (2 kHz, 4 kHz,
8 kHz)
m 20
Category C3 (2 kHz, 4 kHz,
8 kHz)
m 50
Max. motor cable length
unshielded
without EMC category m -
Technical data
3-phase mains connecon 480 V
Rated data
