EDS94AYCEN EN 9.0 - 09/2012 L 15
E94AYCEN communication manual (Ethernet)
Technical data
General data and operating conditions
4 Technical data
4.1 General data and operating conditions
Area Values
Order designation E94AYCEN
Communication profile GCI, based on TCP/IP
Communication medium S/FTP (screened foiled twisted pair, ISO/IEC 11801 or EN 50173), CAT 5e
Interface RJ45: Standard Ethernet (in accordance with IEEE 802.3), 100Base-TX (Fast
Ethernet)
Network topology Line, star
Ethernet port 9410 (GCI)
Baud rate • 10 Mbps
• 100 Mbps
Transmission mode Half duplex / full duplex
Switching method Store and forward
Switch latency 125 μs at maximum telegram length
Voltage supply The communication module is solely supplied with voltage by the standard
device.
Conformities, approvals • CE
•UL
Servo Drives 9400 hardware manual
This manual contains data on ambient conditions and the electromagnetic
compatibility (EMC) which also apply to the communication module.
