Leroy-Somer DIGIDRIVE SE2.5T User Manual

Installation and commissioning
DIGIDRIVE
Variable speed drive
Réf. 3218 GB - 4.33 / d - 02.02
LEROY-SOMER
15
1.4.2 - Installation in cabinet
Table of losses in Watts at 230V Table of losses in Watts at 480V
DIGIDRIVE
rating
Switching frequency
3 kHz 6kHz 12kHz
0.5M 17 18 20
1M 22 24 27
1.2M 34 37 42
1.5M 50 56 63
DIGIDRIVE
rating
Switching frequency
3 kHz 6kHz 12kHz
1.5M/TL 48 54 62
2M/TL 63 69 80
2.5M/TL 82 88 103
3.5M/TL 114 125 146
DIGIDRIVE
rating
Switching frequency
3 kHz 6kHz 12kHz
5.5TL 156 174 206
8TL 210 230 265
11TL 280 305 335
DIGIDRIVE
rating
Switching frequency
3 kHz 6kHz 12kHz
1.5T 35 43 63
2T 44 57 79
2.5T 61 77 105
3.5T 77 97 130
4.5T 95 122 159
5.5T 126 158 192
8T 130 190 295
11T 215 270 385
16T 280 400 570
22T 345 495 700
27T 545 660 885
33T 730 870 1145
40T 950 1130 1485
50T 1090 1325 1800
1.4.3 - Table of forced ventilation flow rates
Forced
DIGIDRIVE rating
2.5M/TL
5.5TL
2.5T 8T(L) 16T 33T
ventilation
and 3.5M/
TL
to 5.5T to 11T(L) to 27T to 50T
Flow rate
(m
3
/hr) 72 72 72 95 153 320
