Installation and commissioning
DIGIDRIVE
Variable speed drive
14
Réf. 3218 GB - 4.33 / d - 02.02
LEROY-SOMER
1.4 - Environmental characteristics
1.4.1 - Table
Characteristics Level
Operating
temperature
• -10°C to 40°C
• Can operate at up to 50°C:
- at 3 kHz: no derating up to 22T.
For 27T to 50T ratings, derate Isn (40°C) by 3% for each
additional degree.
- at 6 kHz: derate Isn (40°C) by 2% for each additional degree
(5% for 1.5T, 16T and 22T ratings).
- at 12 kHz: derate Isn (40°C) by 5% for each
additional degree (3% for 33T to 50T ratings).
CAUTION:
In order for the drive to comply with UL standards, the
operating temperature must not exceed 40°C.
Storage
temperature
•-40°C to +60°C, 12 months maximum (see section 6.2 for
drive care).
Altitude
• ≤ 1000m without derating
• Isn derated by 1% for every 100 m above 1000 m
(4000 m max)
Relative humidity Up to 95% non condensing
Vibration Tested in accordance with standards IEC 68-2-34, IEC 68-2-36 and
Shocks Tested in accordance with standard IEC 68-2-29
EMC
Immunity: EN50082-2 and EN61800-3
• Conforms to EN 50081-1 (for 0.5M to 1.5M ratings), to
EN 50081-2 (for 1.5M/TL to 50T ratings) and EN 61800-3
first environment with RFI filter (see section 3.5.4.2).
CAUTION:
This product conforms to standard IEC 61800-3 for
restricted distribution.
In a residential environment, the drive may produce radio
interference; in this case, the user should take the necessary
measures.
Index of protection IP 20 (with cable glands)
Maximum number of
starts
• Via the control terminal block = unlimited
• 20 power-ups per hour (wait 3 min between
power-ups)
Ventilation Fan cooling from 2.5M/TL and 2.5T ratings upwards
