Installation and commissioning
DIGIDRIVE
Variable speed drive
80
Réf. 3218 GB - 4.33 / d - 02.02
LEROY-SOMER
7 - OPERATING EXTENSIONS
7.1 - Type 1 mains filters
7.1.1 - Characteristics
Mains filters are used to reduce the drive electromagnetic emissions, and thus comply with
European standards EN 50081-1 and EN 50081-2 (see section 3.5).
CAUTION:
Use one mains filter for each drive.
Note: The filters proposed for the DIGIDRIVE are UL approved.
DIGIDRIVE
rating
Characteristics
Voltage (V) Filter reference
Rated
current
(A)
Max. length
of motor
cables
(m)
Energy
losses
(W)
Maximum
leakage
current
(mA)
Protection
0.5M to 1.5M 240 1-ph FLT 5594-12 12 20 6 4 IP20
1.5M/TL to 3.5M/TL
240 1-ph FLT 5594-26 26 50 6 29.5 IP20
240 3-ph FLT 5901-17 17.1 15 6 33 IP20
5.5TL 240 3-ph FLT 5901-30 30.5 20 11 14.1 IP20
1.5T to 5.5T 480 3-ph FLT 5901-17 17.1 15 6 33 IP20
8TL and 11 TL 240 3-ph FLT 5901-30 30.5 15 11 14.1 IP20
8T and 11T 480 3-ph FLT 5901-17 17.1 15 6 33 IP20
16T and 22T 480 3-ph FLT 5901-33 33 15 12 14.1 IP20
27T 480 3-ph FLT 5901-37 37 20 16 24.5 IP20
