Installation and commissioning
DIGIDRIVE
Variable speed drive
24
Réf. 3218 GB - 4.33 / d - 02.02
LEROY-SOMER
3.4 - Description of cables and protective devices
3.4.1 - General characteristics
• It is the responsibility of the user to connect the DIGIDRIVE and fit protective
devices in accordance with the legislation and regulations in force in the country
of use. This is particularly important as regards the size of the cables, the type and
size of fuses, the earth or ground connection, powering down, acknowledging faults,
insulation and protection against overcurrents.
• The following table is given for information only, and must under no
circumstances be used in place of the current standards.
* The recommended cross-sections are given for a single-wire cable whose maximum length
is 10 metres. Above this, the line drops due to the length must be taken into account.
Note:
• The temperature withstand of the cables used for the control and power cables must be at
least 105°C.
• The protective fuses must conform to EN 60269 parts 1 and 2.
DIGIDRIVE
rating
Examples of cable cross-sections (mm
2
) * Input
protective
fuses
(gG)
(A)
Maximum length of
motor cables
(m)
Motor
Mains
Braking
resistor
Remote control
(shielded)
1 ph 3 ph 1 ph 3 ph
0.5M 1.5 1.5 - - ≥ 0.5 6 -
75
1M 1.5 1.5 - - ≥ 0.5 10 -
1.2M 1.5 1.5 - - ≥ 0.5 16 -
1.5M 1.5 1.5 - - ≥ 0.5 16 -
1.5M/TL 1.5 1.5 1.5 1.5 ≥ 0.5 16 10
100
2M/TL 1.5 2.5 1.5 1.5 ≥ 0.5 20 16
2.5M/TL 1.5 2.5 1.5 1.5 ≥ 0.5 25 16
3.5M/TL 1.5 4.0 1.5 1.5 ≥ 0.5 32 20
5.5TL 2.5 4.0 2.5 ≥ 0.5 - 32
8TL 4.0 - 4.0 4.0 ≥ 0.5 - 32
150
11TL 4.0 - 4.0 4.0 ≥ 0.5 - 32
1.5T 1.5 - 1.5 1.5 ≥ 0.5 - 10
100
2T 1.5 - 1.5 1.5 ≥ 0.5 - 10
2.5T 1.5 - 1.5 1.5 ≥ 0.5 - 10
3.5T 1.5 - 1.5 1.5 ≥ 0.5 - 16
4.5T 1.5 - 1.5 1.5 ≥ 0.5 - 16
5.5T 1.5 - 2.5 1.5 ≥ 0.5 - 16
8T 2.5 - 2.5 2.5 ≥ 0.5 - 16
150
11T 2.5 - 2.5 2.5 ≥ 0.5 - 20
16T 4.0 - 4.0 6.0 ≥ 0.5 - 32
22T 6.0 - 6.0 6.0 ≥ 0.5 - 40
27T 10 - 10 10 ≥ 0.5 - 50
33T 10 - 10 10 ≥ 0.5 - 63
60
40T 16 - 16 16 ≥ 0.5 - 80
50T 16 - 16 16 ≥ 0.5 - 100
