Installation and commissioning
DIGIDRIVE
Variable speed drive
Réf. 3218 GB - 4.33 / d - 02.02
LEROY-SOMER
23
CAUTION:
The +24V source can supply a total
current of 100 mA, including the logic
output (terminal 8).
For example: if the consumption of the
logic output is 30 mA, the +24V source
will only be able to supply 70mA.
7
+24V source
14
Voltage accuracy ± 10%
Maximum output
current
100mA
Protection Designed to
tolerate a
permanent short-
circuit at the 0V
common
8 Logic output
Voltage range 0 to +24V
Absolute maximum
voltage range
-1V to +35V in
relation to the 0V
common
Maximum output
current
50mA (at +24V)
Output impedance 10 kΩ
Update time 1.5 ms
Factory setting Zero frequency
9 Logic input: Unlock
10 Logic input: Forward
11 Logic input: Reverse
12
Logic input: Reference
selection
13
Logic input: Jogging or
reference selection
Voltage range 0 to +24V
Absolute maximum
voltage range
-18V to +35V in
relation to the 0V
common
Rated threshold
voltage
+10V
Input impedance 7.5 kΩ
Sampling time 1.5 ms
Logic levels
in positive logic
(factory setting)
Level 0: < +9.5V
(open circuit)
Level 1: > +10.5V
(closed circuit)
Logic levels
in negative logic
(see section 4.4)
Level 0: > +10.5V
(open circuit)
Level 1: < +9.5V
(closed circuit)
15
Relays
16
Voltage/Current 240V~/2A
30VDC/6A
Contact insulation 2.5kVAC
Update time 6 ms
Contact operation: Open: off or faulty
Closed: drive
operational
