Installation and commissioning
DIGIDRIVE
Variable speed drive
Réf. 3218 GB - 4.33 / d - 02.02
LEROY-SOMER
5
FOREWORD
This manual describes the commissioning of DIGIDRIVE digital technology variable speed
drives. It gives details of all the procedures to be carried out during intervention on the drive
and presents the various extensions available.
DIGIDRIVE
Brake
parallel shaft
bevel gear
coaxial
LS or LS MV motor
Forced
ventilation
Induction motor
Gearboxes
Options
Communication
Filter option
4 quadrant options
1.5M/TL rating upwards
RF
FLT
Serial
link
UNIPADDIGISOFTFIELDBUS
OPTIONS
FLASHKEY
M
DIGIDRIVE
01 Vitesse minimum (Hz)
Minimum speed
02 Vitesse maximum (Hz)
Maximum speed
03 Accélération (s/100Hz)
Acceleration rate
04 Décélération (s/100Hz)
Deceleration rate
05 Référence vitesse
Speed reference selec
Mettre le variateur hors tension 10min avant de déposer le capot
Power down unit 10min before removing cover
06 Courant nominal moteur (A)
Motor rated current
07 Vitesse nominale moteur (min
-1
)
Motor rated speed
08 Tension nominale moteur (V)
Motor rated voltage
09 Cos ϕ
Power factor
10 Niveau de paramétrage
Parameter access
CD Rom + cable
with integral
RS 232/RS 485
converter
M
Copy key
option
PM10V
Bipolar analogue input
option
