Installation and commissioning
DIGIDRIVE
Variable speed drive
68
Réf. 3218 GB - 4.33 / d - 02.02
LEROY-SOMER
:Number of motor poles
Adjustment range : Auto, 2P, 4P, 6P, 8P
Factory setting : Auto
Auto: the drive automatically calculates
the number of poles according to the
rated speed (0
0
7
7
) and the rated
frequency (3
3
9
9
).
2P: 2-pole motor (3000 min
-1
).
4P: 4-pole motor (1500 min
-1
).
6P: 6-pole motor (1000 min
-1
).
8P: 8-pole motor (750 min
-1
).
:Serial link mode
Adjustment range : AnSI, rtu, FbuS
Factory setting : AnSI
This is the operating mode for the serial
port.
AnSI: 2-wire "half duplex" serial link
ANSI protocol.
rtu: Modbus RTU protocol.
FbUS: used when a fieldbus interface is
installed. 4
4
2
2
"Transmission speed" is then
automatically set at 19200 bauds.
:Transmission speed via
serial link
Adjustment range : 2.4 - 4.8 - 9.6 - 19.2
Factory setting : 4.8
Used to select the data transfer speed.
2.4: 2400 bauds.
4.8 : 4800 bauds.
9.6: 9600 bauds.
19.2: 19200 bauds.
:Serial link address
Adjustment range : 0 to 24.7
Factory setting : 1.1
Used for ANSI communication to define the
drive address. Any value containing a zero
should be avoided as these values are
used to address groups of drives.
:Software version
Adjustment range : 1.00 to 99.99
Indicates the first 2 numbers of the software
version installed in the drive.
:Station address
Adjustment range : 0 to 255
Factory setting : 0
When a fieldbus (DIGIDRIVE option) is
being used, set the station address.
:Fieldbus transmission
speed
Adjustment range : 0 to 9
Factory setting : 0
When a fieldbus (DIGIDRIVE option) is
being used, set the fieldbus transmission
speed.
:Fieldbus diagnostics
Adjustment range : ± 9999
Factory setting : 0
When a fieldbus (DIGIDRIVE option) is
being used, set the fieldbus diagnostics.
4
4
0
0
4
4
1
1
4
4
2
2
4
4
3
3
4
4
4
4
4
4
5
5
4
4
6
6
4
4
7
7
