Digital Pressure Indicator DPI - Bedienungsanleitung
40 Friedrich Leutert GmbH & Co. KG
» Main menu «
Measure engine
Show data
Delete data
» Main menu «
Measure engine
Show data
Delete data
» Show data «
Main Engine
AUX Engine 1
}
}
}
» Measure engine «
Main Engine
AUX Engine 1
AUX Engine 2
}
» Select Cylinder «
Cylinder no: 01
Cylinder no: 02
}
» Cylinder : 01 «
Avg. press. : 45
Max. press. : 46
Min. press. : 47
» Cylinder : 02 «
Avg. press. : 45
Max. press. : 46
Min. press. : 47
» Cylinder : 01 «
Boost: 4.00
Cycles: 020
@RPM: 360
}
}
}
» Main menu «
Measure engine
Show data
}
6 Organize measurement data in the handheld device
6.1 View data records on the handheld device
While the measured value is being recorded you can see on the DPI display
some of the determined data such as speed, peak and differential pressure.
After completing the series of measurements you can view the complete
data sets on the DPI handheld.
The saved measuring values of the selected cylinder are displayed.
6) Scroll with
or to view the single measured values.
7) Use the key to switch to the next cylinder or leave the ‘Show
data’ menu by pressing the button to return to the superordi-
nate menu.
Switch off the DPI handset by pressing the button for approx. 2 sec-
onds.
1) Press the button for approx. 1 second to switch on the handheld
device. The main menu appears after the start screen. Use the but-
tons or to switch between the lines.
2) Confirm with if the line ‘Show data’ is marked with the } arrow.
4) If the chosen engine is marked with the arrow in the display, confirm
the selection with button .
3) The saved motors are displayed. Scroll down this list with the vertical
arrow keys or .
5) The measured cylinders are displayed. Scroll with the keys or ,
until the chosen cylinder is marked with the } arrow. Confirm with
the key .
