Digital Pressure Indicator DPI - Bedienungsanleitung
44 Friedrich Leutert GmbH & Co. KG
7.4 Changing the batteries
If the battery is to be replaced or removed from the DPI, please proceed as
follows:
1) Use a fl at-blade screwdriver to screw off the cover of the battery
compartment. The fastening screw is captive and the shoulder strap
is on the cap.
2) Remove the old ones and insert the new ones. Take notice of the
polarity.
3) Put the cover cap back on and screw it on.
CAUTION
Switch off the DPI hand-held device and disconnect the charger be-
fore beginning the procedure.
NOTICE
Use identical types when replacing the battery.
Make sure that you have already downloaded and saved the mea-
surement data to the PC or that you no longer need the data.
Environmental information
Please note the RoHS directive 2011/65 / EU (RoHS-II) and BattG and
do not dispose the batteries in the household waste for the sake of
the environment.
