Friedrich Leutert GmbH & Co. KG 9
Digital Pressure Indicator DPI - Bedienungsanleitung
2.4 Software
2.4.1 Description
After measuring the engine the measuring values saved in the handheld
device are transferred to the PC and can be displayed with the DPI soft-
ware and evaluated in detail. To analyze the engine data different visu-
alization modes are available (pressure diagram, PV diagram, bar graphs,
tabular information).
To operate the DPI software you can use the commands in the menu bar,
the four tabs for selecting the display mode and various buttons.
The software enables data export, report generation or sending of the
data by email with just a few clicks.
In addition the software is used for comfortable configuration of the hand-
held device.
Since the software is in English language basic knowledge of English is fa-
vorable but not a requirement. In the manual you get a detailed description
for each command which enables you to work with the program without
any foreign language skills.
Menu commands
Tabs to select the display mode
Command buttons
LED shows connection of
handheld device on the PC
Display area
