9.3 Binary protocol type 3
Notice!
With the BPS Configuration Tool
, the user can individually adapt the binary protocol 1 to
the specific requirements
of the application. The binary protocols 2 and 3, on the other hand,
have a fixed structure and cannot be modified.
9.3.1 Data format
• Baud rate: 19'200 kBaud
• Data bits: 8
• Start bits: 1
• Stop bits: 1
• Parity: even
9.3.2 Telegram structure
9.3.2.1 Query to the BPS 8 (control byte)
Notice!
A0 and A1 are the address bits. If several BPS 8's operate in one network, an address con-
figuration is required.
Notice!
If the F0 bit is set to 1, the diagnostic data are sent in response. Any error indicated is reset.
This may be recognised by the status LED changing from red to green.
Bit no. 7 6 5 4 3 2 1 0
Designation CMD F2 F1 F0 0 0 A1 A0
Bit Function Value Explanation
0A0 0
All read heads are occupied with address 0. The address can only be
changed via the BPS Configuration Tool.
1A1 0
2 -- 0 No function (permanently set to 0).
3 -- 0 No function (permanently set to 0).
4F0
0 Position value request.
1 Diagnostic data request.
5 F1 0 No function (permanently set to 0).
6F2
0 Polygon wheel motor is switched on.
1 Polygon wheel motor is switched off (SLEEP mode
1)
).
1) In order to extend the service life of the device, it can be switched to SLEEP mode. In
SLEEP mode, the motor and laser are switched off. Diagnosis of the read system cannot
be performed.
When reactivating the device, the system takes approx. 5s to boot. It reports after this time
with a message "System ready".
7CMD
0 No function.
1 Byte information is evaluated as a control byte.
