Binary protocol type 3 Leuze electronic
84 BPS 8 Leuze electronic
Response to sleep mode
Notice!
If bit 6 SLEEP is set to 1, the BPS is in SLEEP mode. In a diagnostic response during sleep
mode, the bits CALC, DB and SLEEP are set as follows:
• CALC = 0
• DB = 0
• SLEEP = 1
In SLEEP mode, the data bits P00 to P20 are always 0.
Byte
no.
Designation Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Status byte 0 SLEEP A1 A0 CALC DB OUT ERR
1 Data byte 0 P20 P19 P18 P17 P16 P15 P14
2 Data byte 0 P13 P12 P11 P10 P09 P08 P07
3 Data byte 0 P06 P05 P04 P03 P02 P01 P00
4 XOR logic Exclusive OR logic of bytes 1 to 4
