Fuse Number Function Type Amp Rating
CF 30 Driver's overhead console Micro 5
CF 31 - Micro -
CF 32 Humidity sensor Micro 5
CF 33 Right sliding load space door module Micro 20
CF 34 - Micro -
CF 35 Vehicle connectivity module Micro 5
CF 36 Left sliding load space door module Micro 20
CF 37 Audio amplifier module MCase™ 40
CF 38 HVAC blower module rear MCase™ 40
CF 39 Multiband antenna module Micro 5
CF 40 - Micro -
CF 41 - Micro -
CF 42 - Micro
CF 43 Pump electronic module Micro 15
CF 44 PSR-relay, CPSR-relay Micro 5
CF 45 - Micro -
CF 46 Left heated seat Micro 15
CF 47 Right heated seat Micro 15
CF 48 Auxiliary water pump Micro 10
CF 49 - Micro -
CF 50 Front left door module Micro 20
CF 51 - Micro -
CF 52 - Micro -
CF 53 Infotainment head unit Micro 10
CF 54 - MCase™ -
CF 55 - Micro -
CF 56 Front right door module Micro 20
CF 57 - Micro -
CF 58 - Micro -
CF 59 Infotainment head unit Micro 15
