LEVC VN5 2021 - Page 64

Electrical
3
S023074 PA1
2020-05-12
63
Fuse Number Function Type Amp Rating
CF 03 - Micro -
CF 04 - Micro -
CF 05 - Micro -
CF 06 Driver's display Micro 5
CF 07 Media controls Micro 5
CF 08 Sun sensor Micro 5
CF 09 - Micro -
CF 10 - Micro -
CF 11 Steering wheel module Micro 5
CF 12 Rotary switch START/STOP and
electronic parking brake switch
Micro 5
CF 13 - Micro -
CF 14 - Micro -
CF 15 - Micro -
CF 16 - Micro -
CF 17 - Micro -
CF 18 Climate control module Micro 10
CF 19 Steering wheel lock Micro 7.5
CF 20 Diagnostic socket OBD II Micro 10
CF 21 Centre display Micro 5
CF 22 HVAC blower module front MCase™ 40
CF 23 - Micro -
CF 24 Dashboard switch console
Rain and light sensor module
Rear console switch module
Power seat switch left
Power seat module driver
Micro 7.5
CF 25 Active safety domain master Micro 5
CF 26 - Micro -
CF 27 - Micro -
CF 28 Passenger overhead consoles and
vanity mirror lights
Micro 5
CF 29 - Micro -
