LEVC VN5 2021 - Page 63

3
Electrical
62
PA1
2020-05-12
S023074
Fuse Number Function Type Amp Rating
AF 67 Engine oil pump solenoid Micro 15
AF 68 - Micro -
AF 69 Engine control module (Power supply
1, Power supply 2)
Micro 20
AF 70 Spark plug 1 + ignition coil 1
Spark plug 2 + ignition coil 2
Spark plug 3 + ignition coil 3
Micro 15
AF 71 - MCase™
AF 72 - MCase™
AF 73 - MCase™
AF 74 Vacuum pump control unit MCase™ 40
AF 75 - MCase™
AF 76 - MCase™
AF 77 - MCase™
AF 78 - MCase™
Fuses - Passenger Foot well
Fuse Number Function Type Amp Rating
CF 01 Dash camera/tracker Micro 5
CF 02 - MCase™ -
