Fuse Number Function Type Amp Rating
BF 42 - MCase™ -
BF 43 Vehicle dynamics domain master
(ABS pump)
MCase™ 40
BF 44 Wiper motor module 2 MCase™ 30
BF 45 Heated windscreen (Right) MCase™ shunt
BF 46 Electronic KL15 Micro 5
BF 47 - Micro -
BF 48 RH headlamp unit Micro 15
BF 49 - Micro -
BF 50 - Micro -
BF 51 - Micro -
BF 52 Supplementary restraint system Micro 5
BF 53 LH headlamp unit Micro 15
BF 54 Accelerator pedal sensor Micro 5
AF 55 Electronic gear selector module Micro 5
AF 56 Engine control module Micro 5
AF 57 - Micro -
AF 58 - Micro -
AF 59 - Micro -
AF 60 - Micro -
AF 61 Engine control module (Power supply
3)
Micro 20
AF 62 EVAP purge valve
Solenoid variable valve time inlet B
Solenoid variable valve time exhaust
B
Micro 10
AF 63 Cooling fan relay coil
Vacuum regulator turbo wastegate
control
Micro 7.5
AF 64 - Micro -
AF 65 - Micro -
AF 66 Oxygen sensor 1 (front)
Oxygen sensor Rear
Micro 15
