3
Electrical
60
PA1
2020-05-12
S023074
Fuse Number Function Type Amp Rating
BF 12 High voltage battery Micro 15
BF 13 Electric drivetrain coolant pump Micro 20
BF 14 - MCase™ -
BF 15 Battery coolant water pump 1 MCase™ 20
BF 16 - MCase™ -
BF 17 - MCase™ -
BF 18 - Micro -
BF 19 - Micro -
BF 20 - Micro -
BF 21 - Micro -
BF 22 - Micro -
BF 23 USB connection Micro 7.5
BF 24 12-volt socket front Micro 15
BF 25 - Micro 5
BF 26 - Micro 5
BF 27 - Micro -
BF 28 LH headlamp unit Micro 15
BF 29 RH headlamp unit Micro 15
BF 30 - Micro -
BF 31 Heated windscreen (Left) MCase™ shunt
BF 32 Heated windscreen (Left) MCase™ 40
BF 33 - MCase™ -
BF 34 Front/rear windows washer pump
(Front)
MCase™ 25
BF 35 - Micro -
BF 36 Horn 1
Horn 2
Micro 20
BF 37 Battery backed-up sounder Micro 5
BF 38 Vehicle dynamics domain master
(Valves, EPB)
MCase™ 40
BF 39 Wiper motor module MCase™ 30
BF 40 Window washer pump MCase™ 25
BF 41 Heated windscreen (Right) MCase™ 40
