Levitronix BPS-4H Series User Manual

User Manual for BPS-4H (High Temp.)
www.levitronix.com
PL-2009-03, Rev04, DCO# 21-101
5
System Name
Article #
Pump Head
Motor
Controller
Note
BPS-4H.1
BPS-4H.2
100-90688
100-91074
CP-4.25
BSM-4.10-05
BSM-4.10-30
LC325P
Adaptor/Extension (0.5 - 10m) cables according to Table 3 have to
be ordered as separate article with specified length.
BPS-4H.3
BPS-4H.4
100-91285
100-91442
CP-4.34
BSM-4.11-30
BSM-4.11-05
LC325P
BPS-4H.5
BPS-4H.6
100-91526
100-91530
CP-4.36
BSM-4.11-30
BSM-4.11-05
LC325P
Pump head without suction port.
Table 1: Standard system configurations
Pos.
Component
Article Name
Article #
Characteristics
Value / Feature
1a
1b
1c
Pump Head
CP-4.25
(for up to 180°C liquid)
CP-4.34
CP-4.36 (no suction port)
(for up to 220°C liquid)
100-90565
100-91286
100-91525
Impeller / Housing
Housing Sealing
Fittings Inlet/Outlet
Fitting Suction Port
PTFE / PTFE
a: O-ring Kalrez

1
b: Pin seal with back-up gasket (ePTFE)


Max. Flow
Max. Diff.-Pressure
50 liters/min / 13.2 gallons/min (for sulfuric acid 96% at 150°C)
3.2 bar / 46.4 psi (for sulfuric acid 96% at 150°C)
Tested Hot Chemicals
Sulfuric acid up to 220°C, phosphoric acid up to 180°C
SOM (H
2
SO
4
+O
3
) and SPM (H
2
SO
4
+H
2
O
2
) up to 150°C
2a
2b
Motor
(with water cooling)
BSM-4.10-05 (0.5m)
BSM-4.10-30 (3m)
(for up to 180°C liquid)
BSM-4.11-05 (0.5m)
BSM-4.11-30 (3m)
(for up to 220°C liquid)
100-10061
100-10107
100-10145
100-10182
Housing
ETFE (chemical resistant) coated Aluminum, IP67
Cable / Connectors
2x cables with FEP jacket / 2x circular (M23, IP67)
Cooling Connections
Cooling Flow

0.5  1.0 l/min at 15 - 25°C water, max. pressure = 4 bar
3
Controller
LC325P
100-30011
(Power supply
connector included
in 100-90332)
Voltage
Power
3x 200 or 208 V AC, 1x 230 V AC, ± 10%, 50/60 Hz
2500 W (limited to 1500 W by firmware)
Interfaces for
Standalone Controller
PLC (needs PLC module, see Table 4)
RS232
(for control, debugging with Service Software or operation with LUI-A.1)
Standard Firmware
S4.48
Table 2: Specification of standard components
1: Kalrez
®
is a registered trademark of DuPont Dow Elastomers
Pos.
Component
Sensor Cable (a)
Power Cable (b)
Characteristics
Value / Feature
Article Name
Article #
Article Name
Article #
4
(a+b)
Extension
Adaptor
Cables (FEP)
MCAS-3.2-05 (0.5m)
MCAS-3.2-30 (3m)
MCAS-3.2-50 (5m)
MCAS-3.2-70 (7m)
MCAS-3.2-100 (10m)
190-10244
190-10094
190-10026
190-10245
190-10246
MCAP-4.4-05
MCAP-4.4-30
MCAP-4.4-50
MCAP-4.4-70
MCAP-4.4-100
190-10247
190-10095
190-10096
190-10248
190-10249
Jacket Material
Connectors Sensor
Connectors Power
FEP
Circular, Metallic (IP67) to D-SUB
Circular, Metallic (IP67) to COMBICON
5
(a+b)
Extension
Adaptor
Cables (PVC)
MCAS-3.5-05 (0.5m)
MCAS-3.5-30 (3m)
MCAS-3.5-50 (5m)
MCAS-3.5-70 (7m)
MCAS-3.5-100 (10m)
190-10250
190-10251
190-10169
190-10252
190-10314
MCAP-4.5-05
MCAP-4.5-30
MCAP-4.5-50
MCAP-4.5-70
MCAP-4.5-100
190-10254
190-10255
190-10171
190-10256
190-10257
Jacket Material
Connectors Sensor
Connectors Power
PVC
Circular, Metallic (IP67) to D-SUB
Circular, Metallic (IP67) to COMBICON
Table 3: Specification of adaptor/extension cables
Pos.
Component
Article Name
Article #
Characteristics
Value / Feature
6
Impeller
Exchange Kit
IEK-4.6
(for pump head
CP-4.25)
100-90564
Impeller (A) / O-Ring (B)
Pump Casing Screws (C)
Pump Motor Screws (D)
Imp. Exchange Tool IET-3.1 (E)
IMP-4.7 in PTFE / O-Ring, Kalrez

, 98.02 x 3.53
8 pcs. M8x40, Stainless Steel with PTFE coating
4 pcs. M8x30, Stainless Steel with PTFE coating
POM-C
7
Impeller
Exchange Kit
IEK-4.10
(for pump head
CP-4.34/36)
100-91287
Impeller (A) / Back-Up Gasket (B)
Pump Screws (C)
Motor Screws (D) with O-Ring (E)
Spring Washers (F)
Screw Cup (G) with O-Ring (H)
Imp. Exchange Tool IET-3.1 (I)
Lid Removal Tool LRT-4.1 (J)
IMP-4.7 in PTFE / Gasket in ePTFE
8 pcs. M8x45 (Inox A4)
4 pcs. M8x80 (Inox A4), 4x O-ring (FKM)
12 spring washer (Inox A4) for motor and pump screws
12 pcs. Protection cups (PE-HD) and O-ring (FKM)
POM-C
POM-C
8
PLC Module
PLC-A.1
100-30200
Digital Inputs
Digital Outputs
3x 24 V DC (typical), galvanically isolated
3x closing relay (30 V, 1 A)
Analog Inputs
Analog Outputs
2x 4-20 mA, not galvanically isolated
2x 0-5 V, not galvanically isolated
9
Handheld User Interface
LUI-A.1
100-30300
Interface
RS232
10
Connector Protection
(Sensor and power cables)
LCP-S.3
100-90799
Materials
Dimensions
Purpose
Protection Rating
PP for nuts (b) and tube (a) and FKM/FPM for cable sealing (c)
OD = 50 mm, Length = 186 mm
Chemical protection for connectors
IP67 for FEP adaptor cables, IP65 for PVC adaptor cables
Table 4: Specification of accessories
