2.2 System Overview and General Specification
2.2.1 Basic Stand-Alone System Configuration
With the stand-alone pump system configuration, as illustrated in Figure 5 for the PuraLev
®
i30 and i100 and TBD for the
PuraLev
®
i600 pump system, the speed of the pump can be set manually and the flow can be monitored with a LEVIFLOW
®
flow sensor. The mode of operation can be easily switched to a flow control setup, where the flow is set manually on the
7” multi-touch screen controlled by the integrated PC.
Figure 5: Stand-alone console configuration for PuraLev
®
i30/100 pump system
Figure 6: Stand-alone pump system configuration for PuraLev
®
i600 pump system
Integrated Pump
Driver OEM Model
(with Connector)
Fluid Out
Flow Sensor
LFSC-D
LFS-SU
Single-
Use
Pump
Head
Multi-Touch
Screen 7"
Fluid In
AC Mains Cable
AC Supply
Input
On-Off Button
USB Interface for
Firmware Update
with USB Stick
DC Supply Input
Power to
Integrated
Driver
Flow Sensor
AC/DC Supply
PuraLev
®
Console
Pump Head Socket
(Necessary for DCP
single-use pump heads)
Integrated Pump Driver
OEM Model
(with Connector)
Fluid Out
Flow Sensor
LFSC-D
LFS-SU
Single-
Use
Pump
Head
Multi-Touch
Screen 7"
Fluid In
AC Mains Cable
AC Supply
Input
On-Off Button
USB Interface for
Firmware Update
with USB Stick
Power to
Driver
Flow Sensor
PuraLev
®
Console
DC Supply Input
(with RS485)
AC/DC Supply
(Sealed)
Y-Split Box
(Integrated DC/DC
Converter)
Pump Head Socket
(Necessary for DCP single-use
pump heads)
1
2c
5
2a
3a
3c
3d
2c
14
16a
16b
16c
3b
Multi-Use pump head
option for PuraLev-i30/100
6
11a
17a
17b
18
4c
4a
4b
1
19
11a
2b
Note: When
running with a
Y split box the
driver
connector can
not be used to
attach another
i30/i100 pump.
