Lexicon 960L - Reverse & Surround Reverse

1-4
The Mainframe Lexicon, Inc.
I/O Clock Card
MIDI CONNECTORS (FIVE-PIN DIN FEMALE)
• MIDI In
Accepts MIDI data from other MIDI-equipped
devices.
• MIDI Thru
Retransmits, unchanged, MIDI data received at
the MIDI In connector.
• MIDI Out
Transmits MIDI data generated or modified by the
960L.
TTL WORD CLOCK (BNC)
• Input Loop
Allows the 960L to be synchronized to other
studio equipment.
• Output
Allows studio equipment to be synchronized to
the 960L.
Note:
The 960L can also derive Word Clock from AES
input 1-2, or generate it internally.
Remote Control Connectors
The 960L supports up to two LARC2s. The 960L comes stan-
dard with one LARC2 — an optional second LARC2 can be
purchased separately. The 960L Remote connectors are
for use with the LARC2 controllers only.
IMPORTANT:
Never connect either Mainframe remote port to
anything other than LARC2. Doing so may dam -
age your equipment.
Option Plates
Reserved for future use.
YOUR 960L MAY CONTAIN ANY COMBINATION OF
THE FOLLOWING CARDS:
ANALOG INPUT CARD
The 960L’s analog audio input card has eight female
XLR connectors, all electronically balanced. For
impedances and signal levels, see the Pro d u c t
Specifications located in the Appendix Section of this
manual.
ANALOG OUTPUT CARD
The 960L’s analog audio output card has eight male
XLR connectors, all electronically balanced. For
impedances and signal levels, see the Pro d u c t
Specifications located in the Appendix Section of this
manual.
AES I/O CARD
The 960L’s digital audio inputs and outputs are com-
bined on one card holding four XLR two-channel
female connectors for AES input and four XLR two-
channel male connectors for AES output.
Mains Power Switch
This switch turns the power in the 960L completely
off or on.
Mains Voltage Selector
If your 960L is equipped with a mains voltage selector
switch, before connecting the Mainframe to power mains
make sure the setting matches your local mains voltage.
Refer to the Installation guidelines on p. 1-7 for more
information.
IEC Power Connector
Accepts IEC power cords with mains plugs specific to your
country.
