MIDI960L
MIDI
The MIDI implementation for the 960L is very basic. Since
the implementation is fixed, there is no user interface for
modifying it.
Nomenclature
Numbering in MIDI, i.e. channel number, program num-
bers, etc., can be confusing, since some sources start
counting from zero and others start from one. This descrip-
tion will start from zero. If, for example, your MIDI con-
troller's lowest channel number is 1 (rather than 0), you
should add one to the values found in channel table
below.
MIDI Channel Allocation
The 960L uses a fixed channel allocation. All channels are
used or reserved, which means that 960L should
be the only device on its MIDI cable.
Channel Usage Description
0 Global Channel Not currently in use
1 DSP Card1 Configuration of card
2 DSP Card 2 Configuration of card
3 Unused Reserved for Future Use
4 Machine 1 Program change for machine 1
5 Machine 2 Program change for machine 2, if present in current configuration
6 Machine 3 Program change for machine 3, if present in current configuration
7 Machine 4 Program change for machine 4, if present in current configuration
8 Machine 5 Program change for machine 5, if present in current configuration
9 Machine 6 Program change for machine 6, if present in current configuration
10 Machine 7 Program change for machine 7, if present in current configuration
11 Machine 8 Program change for machine 8, if present in current configuration
12 Unused Reserved for Future Use
13 Unused Reserved for Future Use
14 Unused Reserved for Future Use
15 Unused Reserved for Future Use
