Lexicon 960L User Manual

960L Appendix
A-19
960L MAINFRAME
ANALOG INPUT
Connectors Eight, Female XLR
Impedance 50K Ohm, balanced
Level (for 0 dbFS) +24dBu
Freq Response @48K 20Hz--20KHz, ±1dB
Freq Response @96K 20Hz-40KHz, ±1dB
A/D Conversion 24 bits
128x oversampled
A/D Dyn Range >110 dB (20-20kHz)
THD <.002%
CMRR >50dB
Crosstalk @ 1Khz < -100dB
ANALOG OUTPUT
Connectors Eight, Male XLR
Impedance 50 Ohm, balanced
Level (at 0 dBFS) +24dBu
Freq Response @48K 20Hz-20Khz, ±1dB
Freq Response @96K 20Hz-40Khz, ±1dB
D/A Conversion 24 bits
8x oversampled @ 44.1/48kHz
4x oversampled @ 88.2/96kHz
D/A Dyn Range >110 dB (20-20kHz)
THD <.002%
Crosstalk @ 1kHz < -100dB
A/A PERFORMANCE
Freq Response @48K 20Hz-20Khz, ±1dB
Freq Response @96K 20Hz-40Khz, ±1dB
Dyn Range >107 dB (20-20kHz)
THD <.002%
DIGITAL AUDIO IO
Connectors Four Male XLR Outputs
Four Female XLR Inputs
Format AES/EBU
Word Size 24 bits
SAMPLE RATES
Internal 44.1/48/88.2/96kHz
Accuracy within ±10ppm
External 44.1/48/88.2/96kHz
Lock Range ±1%
GROUP DELAYS (MILLISECONDS)
44.1 kHz 48 kHz 88.2 kHz 96 kHz
A/D 1.44 1.33 0.81 .0.74
A/A 2.42 2.23 1.80 1.66
D/A 1.59 1.42 1.35 1.25
D/D 0.54 0.50 0.36 0.33
SYNCHRONIZATION
TTL Word Clock Input * 75 Ohm, BNC
self-terminating loopthru
TTL Word Clock Output* Low Z, BNC
(*Falling edge marks start of frame)
CLOCK JITTER
Intrinsic Exceeds AES3 Amendment 1
Jitter Gain Exceeds AES3 Amendment 1
CONTROL INTERFACES
LARC2 Ports 2
MIDI ** In/Out/Thru
(**supports program change)
ALGORITHMS
Ambience (48K Stereo & Surround)
Chamber (48K Stereo & Surround)
Plate (48K Stereo & Surround)
Reverse (48K Stereo & Surround)
Random Hall (48/96K Stereo & Surround)
Ambient Chamber (48K Surround)
STANDARD HARDWARE CONFIGURATIONS
DSP/CPU Card Compartment
One System CPU Card
One Reverb DSP Card
Two Spare DSP card slots
One MIDI Card
Standard I/O Card Configurations
Option A: Analog Input Card
Analog Output Card
AES/EBU Digital I/O Card
I/O Clock Card
Spare I/O Card slot
Option B: AES/EBU Digital I/O Card
I/O Clock Card
Three Spare Slots
Storage Media Hard Disk
3.5" Floppy Disk Drive
CD-ROM Drive
