2-3
Basic Operation
The front panel Effect buttons light to show you which effect blocks are active.
— When you're scrolling through programs, they'll change to show you the
effects in any displayed program. Once you stop scrolling, they'll return to
display of the effects that are active in the currently loaded program.
To bypass any active effect, press its button. The light will turn off and the effect
will be bypassed. Press the button again to make the effect active again.
Press and hold down any effect button to display the name of the effect and
information about its status in the program (on or off).
Mix and level controls in the MPX 1 are brought right out to the front panel for
easy access. From any mode of operation, just press Mix to access these
controls. The button LED will flash to let you know Mix is active.
The display will show mix and level labels on the upper line, and the current
settings on the lower line. One of the values on the lower line will be flashing to
let you know which is selected for adjustment. Use the < and > buttons to select
Mstr Mix, Mstr Level, or to step to the Mix and Level controls for any active effect
in the currently running program. Use the knob to adjust the flashing parameter
value.
Effect Bypass
The active effects of the currently
loaded program are lighted. Press
any lighted button to turn the effect
off. Press it again to make the effect
active again.
Mix
From anywhere, press Mix to ac-
cess mix and level parameters for
the system, or for any active effect.
The knob will adjust the flashing parameter value.
Use > to step to the Mstr Level parameter, or to step forward
to the next screen of Effect Mix and Level parameters.
Mstr Mix Level
> 100% 0dB
When you've finished adjusting the mix and level controls, push Mix to return to
the previous display.
