Lexicon MPX 1 - REV 1 User Manual

5-9
System Controls
Options: MIDI Reset
The MPX 1 recognizes the “Reset All Controllers” MIDI message. When
received, all patched parameters are reset to their stored values. Patched
parameters may also be reset from the MPX 1 front panel —in System mode
select Ctl Send from the MIDI menu and press Options, then press Yes. (The
message will be transmitted from the MPX 1 as well). If you do not want to
perform the reset, press Options to exit.
The Ctl Smooth parameter is an intelligent filter that provides a smoothing
function for incoming MIDI data. At 100, the filter is essentially bypassed. With
decreasing values, the filter becomes more sluggish in its response to small MIDI
controller value changes while maintaining a fast response to large changes.
This is useful for smoothly interpolating sparse MIDI controller data. As the value
is lowered, the filter's response slows for both large and small MIDI controller
value changes.
You can choose to have the MPX 1 transmit MIDI Clock at the current tempo rate
by setting this control to On and Tempo Source (in the Edit menu) to Internal.
If this control is set to Off, MIDI Clock will not be transmitted.
This control is provided for control of one or more additional MPX 1s. Select On
to have values resulting from front panel operations sent out as System
Exclusive messages.
Options: Xmit Device ID
Press Options to access the Xmit Device ID screen where you can select 0-126
or All to identify the target MPX 1s.
This control is provided for communication with one or more additional MPX 1s,
or computer editor software. On (the default setting) allows System Exclusive
messages to be received by the MPX 1.
Options: Receive Device ID
Press Options to access the Receive Device ID screen where you can select
0-126 to identify the MPX 1.
Press Options to
access MIDI Reset.
Press Yes in response to
the display prompt to reset all
patched parameters to their
stored values. Press Options
again to return to the MIDI Ctl
Send menu.
Ctl Smooth
Clock Send
Automation
SysEx
Press Options to
access Xmit Device
ID selection. Press Options
again to exit.
Press Options to ac-
cess Receive Device
ID selection. Press Options
again to exit.
