Lexmark C734 - Assembly 6: Top

To Next Page

To Previous Page

7-12 Service Manual

5026

Assembly 6: Top

Index P/N

Units/

mach

Units/

FRU

Description

6—1 40X5122 1 1 Color-On-Demand assembly

2 40X5109 1 1 Cooling fan

3 40X5130 1 1 Top cover camshaft assembly

4 40X5108 1 1 Cartridge cooling fan
