Index I-1
5026
Index
Numerics
1xx service error codes 2-162-18
24 V interlock switch
parts catalog
7-12
removal 4-47
service check 2-119
2xx paper jam codes 2-182-29
clearing jams 3-39
error jam locations 3-38
3x–8x attendance messages 2-82-15
5 V interlock switch
cable removal
4-45
parts catalog 7-6
service check 2-118
9xx service error codes 2-302-36
A
acronyms 1-15
Action for Prompts 3-29
adjustments 4-8
Align Motor Test 3-9
alignment
diagnostics menu
3-8
printhead 4-8
Auto Align Adj 3-28
Auto Color Adj 3-28
B
bellcrank
left bellcrank
4-97
parts catalog 7-5
right bellcrank 4-138
bezel
parts catalog
7-2
removal 4-28
bin full sensor
cable service check
2-106
flag removal 4-49
parts catalog 7-12
removal 4-49
black retract, see color on demand assembly
blower, see cooling fan
4-61
Button Test 3-12
buttons
description
2-2
parts catalog (operator panel) 7-2
removal 4-29
C
cables
cartridge motor 1/fuser
4-51
cartridge motor 2/3 cable 4-53
HVPS cable 4-96
motor driver cable 4-101
MP feeder/duplex motor 4-107
operator panel 4-108
operator panel ground 4-110
option cable 4-111
transport cable 4-156
transport motor cable 4-158
USB connector 4-159
cables, parts catalog 7-13
cartridge cooling fan
parts catalog
7-12
removal 4-50
service check 2-113
cartridge motor
service check
2-102, 2-103, 2-107
cartridge motor 1/fuser cable 4-51
cartridge motor 2/3 cable, removal 4-53
Clear Custom Status 3-31
Color Adj State 3-28
Color Alignment 3-28
Color Lock Out 3-25
color on demand (COD)
color lock out
3-25
parts catalog 7-12
service check 2-53
color on demand assembly
removal
4-55
Color Trapping 3-26
configuration ID 3-20
configuration menu
accessing
3-1
Action for Prompts 3-29
Auto Align Adj 3-28
Auto Color Adj 3-28
available tests 3-24
Clear Custom Status 3-31
Color Adj State 3-28
Color Alignment 3-28
Color Lock Out 3-25
Color Trapping 3-26
Demo Mode 3-27
Disk Encryption 3-30
Download Emuls 3-27
Duplex Gloss 3-30
Energy Conserve 3-27
Enforce Color Order 3-28
Env Prompts 3-29
Event Log 3-26
exit Config Menu 3-31
Factory Defaults 3-27
Font Sharpening 3-30
Jobs on Disk 3-29
Menu Settings Page 3-26
Motor Calibration 3-29
Panel Menus 3-26
Paper Prompts 3-29
PPDS Emulation 3-27
