Lexmark C734 User Manual

3-2 Service Manual
5026
Diagnostics menu
Note: Tray 2 refers to the 550-sheet tray located in the 550-sheet option assembly.
Diagnostics menu structure
When the Diagnostics mode is entered, each Diagnostics main menu item displays on the operator panel. When
a diagnostic test is selected from the main menu, a sub menu displays and each individual test displays in the
order shown. Any options that are referred to in the menus are displayed when the option is installed.
Available tests
The tests display on the operator panel in the order shown:
REGISTRATION
Top Margin See “Registration” on page 3-5.
Bottom Margin
Left Margin
Right Margin
Skew See “Skew” on page 3-5.
Quick Test See “Quick Test” on page 3-7.
ALIGNMENT MENU
Cyan See “Alignment” on page 3-8.
Yellow
Magenta
Factory Scanner A summary page for all the color alignment settings. Can be used in
place of alignment pages for each individual color.
Factory Manual
MOTOR TESTS (order differs depending upon model)
Align Motor Test Note: Many of these tests require special conditions in order to
successfully test the motors. See “General motor tests procedures”
on page 3-9.
Cart 1
Cart 2
Cart 3
CAM
COD
DUPLEX
Fuser
MPF
Transfer Belt
Option Motors
Tray 1 Pickup
