2 Using the handholds on each side, lift and pull the fuser out
of the printer.
d Place the fuser on a flat surface with the blue thumb screws
facing you.
e Pull and then rotate the green rectangular knob clockwise to
unlock the top paper guide.
1
2
f Press the green arrow tab to the left, and then lift the top paper
guide.
2
1
g Firmly grasp the jammed paper on each side, and then gently
pull it out.
Note: Make sure all paper fragments are removed.
h Close the top paper guide. Make sure both sides of the paper
guide are firmly seated.
i Pull and then rotate the green rectangular knob
counterclockwise to firmly secure the top paper guide.
1
2
j Reinstall the fuser unit:
1 Align the fuser unit using the handholds on each side, and
then insert it back into the printer.
2 Turn the screws clockwise to fasten the fuser securely.
4 Close the printer top access cover, and then close the front door.
5 Depending on your printer model, touch Continue, jam cleared or
press
.
