Clearing paper jams
2 Remove any paper on the transfer belt.
If the paper source was the multipurpose feeder, check the area between the multipurpose
feeder and the transfer belt.
Transfer belt
Warning: Do not use any pointed objects to remove the paper. This could cause permanent
damage to the transfer belt.
3 Check the fuser area and top cover for additional jams.
If there is no jam in the fuser area or top cover, close the top cover and front door, and then
press
Go. If a jam is present, continue with step 4.
Note: If you need instructions on how to close the top cover, see Closing the top cover.
4 Lift the fuser pressure release lever.
200 Paper Jam <x> Pages Jammed (Check Areas A-F, T1-5, MPF)
114
To Next Page
