Printing
Understanding the operator panel
The printer operator panel has a two line by 16-character liquid crystal display (LCD), five buttons,
and one indicator light.
Ready
LCD
1
Menu
2
Select
3
Return
4
Go
5
Stop
6
Indicator light
Indicator light
The indicator light gives information about the status of your printer. If the light is:
• Off, the printer is off
• On, the printer is on, but idle
• Blinking, the printer is on and is busy
Using the operator panel buttons
Use the five operator panel buttons to open a menu, scroll through a list of values, change printer
settings, and respond to printer messages.
The numbers 1 through 6 appear beside the operator panel buttons; these numbers are used to
enter personal identification numbers (PIN) for Print and Hold jobs. For more information, see
Using
the Print and Hold function.
Understanding the operator panel
9
