Table of Components
1 Charge Roll 16 Press Roll 31 Duplex Bottom Transport Roll
2 LED Head 17 Transfer Belt 32 Duplex Exit Roll
3 Developer Roll 18 Transfer Belt Drive Roll 33 Paper Exit Roll
4 Primary Transfer Roller 19 Pickup Roll (MP Feeder) 34 Registration Sensor Actuator
5 Drum Cleaning Blade 20 Feed Roll (MP Feeder) 35 Fuser Input Sensor Actuator
6 Photoconductor 21 Separation Roll (MP Feeder) 36 Duplex Exit Sensor Actuator
7 Doctor Blade 22 Pickup Roll (Std Tray) 37 Paper Exit Sensor Actuator
8 Supply Roll 23 Feed Roll (Std Tray) 38 Transport Roll
9 Toner Cartridge 24 Separation Roll (Std Tray) 39 MPF Feed Roll
10 Secondary Transfer Roll 25 Registration Roller (IN) MP Feeder 40 Bin Full Detection Lever
11 Transfer Belt Cleaning Blade 26
Registration Roller (OUT) MP
Feeder
12 Fuser Heater 27
Standard Registration Roller (IN)
Std Tray
13 Hot Roll 28
Standard Registration Roller (OUT)
Std Tray
14 Fuser Belt 29 Duplex Input Roll
15 Fuser Roll 30 Duplex Transport Roll
