Lexmark C925 - X925 Operator Panel

Lexmark C925/X925 Color Product Study Guide Rev 2.3
For Training Purposes Only 6/21/2011
40
X925 Operator Panel
Number Item Description
1 Display Shows the status of the printer
2 Indicator light
• Off – The printer is off.
• Blinking green – The printer is warming up, processing data, or printing.
• Solid green – The printer is on, but idle.
• Solid red – Operator intervention is needed.
3 Sleep
Enables Sleep Mode
Note: Touching the screen or any hard button presses can cause the printer to wake from
Sleep Mode.
4 Keypad Allows you to enter numbers, letters, or symbols
5 Start
• Press to initiate the current job indicated on the display
• From the home screen, press to start a copy job with the default settings.
• If pressed while a job is scanning, the button has no effect.
6 Stop/Cancel
Stops all printer activity
Note: A list of options is displayed once Stopped appears on the display.
7
PictBridge and USB
port
Allows the user to connect a PictBridge-enabled digital camera, a USB Bluetooth adapter,
or a flash drive to the printer
Note: Only the front USB port supports flash drives.
8 Home Lets you navigate back to the home screen
1 2 3
4
5
6
7 8
