Lexmark C925/X925 Color Product Study Guide Rev 2.3
For Training Purposes Only 6/21/2011
31
Number Part name
Affected CRU / FRU part catalog
name
1
ADF paper length and width sensors - photo reflect /
multi-point contact
Tray paper size sensor
2
Paper pass sensor -photo reflect Duplex timing sensor
3
ADF paper present - photo interrupt ADF paper path sensor
4
ADF cover open ADF paper path sensor
5
Pick roll ADF pick roll (CRU)
6
Pick roll position sensor -Photo interrupt ADF paper path sensor
7
Feed roll ADF pick roll (CRU)
8
Separator roll ADF Separator roll (CRU)
9
Paper gap sensor - photo interrupt ADF paper path sensor
10
Paper in sensor -Photo reflect Scan sensor
11
Scan roll ADF main feed unit
12
Scan sensor -Photo interrupt Scan sensor
13
Takeaway roll ADF main feed unit
14
ADF paper exit sensor - Photo interrupt Duplex out sensor
15
Stack roller ADF main feed unit
16
Pass roller ADF main feed unit
