Repair information
• “Removal precautions” on page 199
• “Removal procedures” on page 215
• “Cover removals” on page 215
• “Base printer removals” on page 229
• “Options removal” on page 306
Removal precautions
CAUTION—SHOCK HAZARD: For personal safety and to prevent damage to the printer, remove the power cord
from the electrical outlet before you connect or disconnect any cable, electronic board, or assembly. Disconnect
any connections between the printer and the PCs/peripherals.
CAUTION—POTENTIAL INJURY: The printer weight is greater than 18kg (40 lb) and requires two or more
trained personnel to lift it safely. Use the hand holds on the side of the printer. Make sure your fingers are not
under the printer when you lift or set the printer on the floor or another stable surface.
Handling ESD‑sensitive parts
Many electronic products use parts that are known to be sensitive to electrostatic discharge (ESD). To prevent damage
to ESD-sensitive parts, use the following instructions in addition to all the usual precautions, such as turning off power
before removing logic boards:
• Keep the ESD-sensitive part in its original shipping container (a special “ESD bag”) until you are ready to install the
part into the machine.
• Make the least-possible movements with your body to prevent an increase of static electricity from clothing fibers,
carpets, and furniture.
• Put the ESD wrist strap on your wrist. Connect the wrist band to the system ground point. This discharges any static
electricity in your body to the machine.
• Hold the ESD-sensitive part by its edge connector shroud (cover); do not touch its pins. If you are removing a
pluggable module, use the correct tool.
• Do not place the ESD-sensitive part on the machine cover or on a metal table; if you need to put down the ESD-
sensitive part for any reason, first put it into its special bag.
• Machine covers and metal tables are electrical grounds. They increase the risk of damage, because they make a
discharge path from your body through the ESD-sensitive part. (Large metal objects can be discharge paths without
being grounded.)
• Prevent ESD-sensitive parts from being accidentally touched by other personnel. Install machine covers when you
are not working on the machine, and do not put unprotected ESD-sensitive parts on a table.
• If possible, keep all ESD-sensitive parts in a grounded metal cabinet (case).
• Be extra careful while working with ESD-sensitive parts when cold-weather heating is used, because low humidity
increases static electricity.
7527
Repair information
199
