Maintenance
Inspection guide
The purpose of this Inspection guide is to aid you in identifying the intervals, based on page count, at which parts must
be Inspected (for visible physical damage), cleaned, or replaced.
If any unsafe conditions exist, find out how serious the hazard could be and if you can continue before you correct the
hazard.
As you service the machine, check for the following:
• Damaged, missing, or altered parts, especially in the area of the On/Off switch and the power supply
• Damaged, missing, or altered covers, especially in the area of the top cover and the power supply cover
• Possible safety exposure from any non-Lexmark attachments
• Printer and input options are sitting flat (for example, not sitting on cables or hanging over a ledge)
• Printer is properly set on any input options
Use the following tables to determine when specified parts should be inspected:
Lexmark CX310, CX410 EVERY
SERVICE CALL
EVERY 200K NOTES
Media tray - All
Media tray side guides Inspect Inspect Check for correct positioning.
Media tray length guides Inspect Inspect Check for correct positioning.
Separation roller Inspect, clean
if needed
Replace Clean with damp cloth.
Tray lift gear assembly Inspect Inspect Ensure correct operation.
Transfer roller Inspect Replace Ensure correct installation.
Fuser Inspect Replace Ensure correct installation.
Media feeders - All
Media tray pick roller Inspect, clean
if needed
Replace Clean with a damp cloth.
MPF pick roller Inspect, clean
if needed
Inspect, clean if
needed
Clean with a damp cloth.
Covers and doors
Rear door Inspect Inspect Ensure correct operation and closure.
Fuser access door Inspect Inspect Ensure correct operation and closure.
Paper path
Duplex path Inspect Inspect Check for media fragments and tears.
7527
Maintenance
319
