Lexmark E460DN - Operator Panel Removal

Repair information 4-55
4513-630, -63W, -6EW
Operator panel removal
1. Remove the nameplate. See “Nameplate removal” on page 3-54.
2. Remove the bezel. See “Bezel removal” on page 3-5.
3. Remove the four screws (A) from the display plate.
4. Lift the operator panel cover, and disconnect the operator panel cable (B).
5. Remove the operator panel.
A
B
