3-16 Service Manual
4513-630, -63W, -6EW
Automatic Darkness Adjustment (Auto Dark Adj)
This setting attempts to optimize the amount of toner used when printing with a specific operating point. Each
time this setting executes, the printer performs the following:
• Calibrates its toner density sensor
• Measures the reflectivity of its bare drum
• Prints patches on the drum and measures the drum’s reflectivity through the patches
• Cleans the transfer roll
• Calculates reflectivity ratios and operating points in order to attain each operating point’s
darkness target
• Modifies the EP mechanism as necessary to adjust toner darkness
No messages are displayed on the operator panel to give any indication that this test is running. When
deactivated, the printer disables.
Reports
This setting prints the Diagnostic menu settings page. Press to print the menu settings page.
Event log
Display Log
Selecting EVENT LOG provides a history of printer errors. The most recent error displays in position 1, and the
oldest error displays in position 10 (if 10 errors have occurred). If an error occurs after the log is full, then the
oldest error is discarded. Identical errors in consecutive positions in the log are entered. All 2xx and 9xx error
messages are stored in the event log as well as the photoconductor kit and maintenance counter resets and
NVRAM resets initiated by the Factory Defaults setting in the UTILITIES menu.
To view the display log:
1. Select Display Log from the EVENT LOG menu.
The error log is displayed one error per display screen. For example:
This error is the first of six errors (it is also the latest error). This error was a 936 service error. To see the
second service error, press . Pressing will display the sixth error as shown:
2. Press Back once to exit the Display log, or press twice to exit the EVENT LOG.
Event 1/6
936 Svc Error
Event 6/6
202.01 Paper Jam
