Lexmark E460DN Service Manual

2-22 Service Manual
4513-630, -63W, -6EW
Printer symptom table
Symptom Action
Fan noisy or fan not working. See “Cooling fan service check” on page 2-24.
Fuser parts melted. See “LVPS/HVPS service check” on page 2-26.
Toner not fused to the media. See “Fuser service check” on page 2-26 or “Solving print
quality problems” on page 2-35.
Paper jams. See “Paper feed service checks” on page 2-28.
Main motor noisy or not moving. See “Main motor service check” on page 2-27.
Media skew. See “Paper feed service checks” on page 2-28.
Printer not communicating with host. See “Parallel or USB port service check” on page 2-30.
Front access door will not close. See “Cover interlock switch service check” on page 2-24.
Operator panel button not responding. See “Operator panel service check” on page 2-28.
Operator panel lights are off or very dim. See “Operator panel service check” on page 2-28.
Blank page. See “Blank page” on page 2-31.
Black page. See “Black page” on page 2-32.
Heavy background. See “Heavy background” on page 2-32.
Light print. See “Light print” on page 2-34.
White or black lines or bands. See “White or black lines or bands” on page 2-34.
Toner on back of page. See “Toner on back of page” on page 2-34.
Media never picks. See “Media never picks” on page 2-29.
Media feeds continuously. See “Media occasionally mispicks or picks multiple sheets
at once” on page 2-29.
Media wrinkled or bent. See “Media “trees,” wrinkles, stacks poorly, or curls” on
page 2-30.
Dead machine (no power). See “Dead machine service check” on page 2-25.
Print quality problems
• Light print
• Blurred characters
• Toner on both sides of media
• Toner not fused
• Streaks
• Blank pages
See “Solving print quality problems” on page 2-35.

Lexmark E460DN Specifications

General

Color	No
Duplex printing	Yes
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	64 MB
Processor frequency	466 MHz
Maximum internal memory	576 MB
Sound pressure level (printing)	53 dB
Total input capacity	300 sheets
Maximum input capacity	850 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	TCP/IP IPv4, IPX/SPX, AppleTalk, LexLink (DLC), TCP/IP IPv6, TCP, UDP
Recommended media weight	75 g/m²
Compatible operating systems	Windows 2000/ME/XP/98/XP Pro/Server 2003/2003 x64 Mac OS X, Mac OS 9.x
Maximum duty cycle	80000 pages per month
Sustainability certificates	ENERGY STAR
Operating altitude	0 - 2500 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC Class B, UL 60950-1 3rd Edition, U.S. FDA, IEC 320-1, CSA, ICES Class B, Energy Star, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB

Weight and Dimensions

Weight	14030 g
Dimensions (WxDxH)	406 x 370 x 260 mm
